| Detection width | 300mm | ||||
| Detection height (mm) | 100mm | 120mm | 150mm | 200mm | 250mm |
| fe | Φ≥0.8mm | Φ≥1.0mm | Φ≥1.2mm | Φ≥1.5mm | Φ≥2.0mm |
| Non-Fe | Φ≥1.2mm | Φ≥1.5mm | Φ≥2.0mm | Φ≥2.5mm | Φ≥3.0mm |
| Sus | Φ≥1.5mm | Φ≥2.0mm | Φ≥2.5mm | Φ≥3.0mm | Φ≥3.5mm |
| PERCEIVABLE METAL | Ferrous,Non-Ferrous,Stainless steel | ||||
| SENSITIVITY ADJUSTMENT | Auto setting | ||||
| ALARM METHOD | Buzz | ||||
| WIDTH OF CONVEYOR BELT | 250mm | ||||
| PRODUCT STORAGE | 99 kinds | ||||
| Conveying speed | Fixed speed 28m/or adjustable speed 10-30m/min[speed can be customized] | ||||
| Power supply | 220V/50-60Hz | ||||
| Motor power | 90w | ||||
| Net weight | 170Kg | ||||
| HS code | 8543709100 | ||||
🧲 Ultra-Sensitive Needle DetectionAdvanced magnetic detection coils and digital signal processing locate broken needles or ferrous fragments as small as 0.8 mm, protecting garments and end users.⚡ High-Speed Scanning
Maintains rapid conveyor throughput while delivering instant detection and rejection, keeping production lines efficient and uninterrupted.🛡️ Safe & Reliable Design
PLC-controlled system with automatic stop and audible/visual alarms ensures operator safety and continuous, fault-free operation.🔄 Automatic Reject Mechanism
Fast pneumatic or mechanical ejectors remove contaminated items without halting production, minimizing downtime and material loss.
⚙️ Customizable Aperture & Conveyor Options
Available in multiple tunnel sizes, belt widths, and sensitivity levels to suit various garment types and factory layouts.
🧩 Easy Integration & Maintenance
Compact, modular construction installs seamlessly on existing sewing or finishing lines. Quick-access panels simplify cleaning and service.
🌿 Energy-Efficient Operation
Optimized circuitry and intelligent standby mode reduce power consumption while ensuring stable 24/7 performance.
🌍 Global Compliance & Certification
Meets international standards, including EU CE and ISO 9001, ensuring dependable performance and smooth global distribution.
| Detection width | 400mm | ||||
| Detection height (mm) | 100mm | 120mm | 150mm | 200mm | 250mm |
| fe | Φ≥0.8mm | Φ≥1.0mm | Φ≥1.2mm | Φ≥1.5mm | Φ≥2.0mm |
| Non-Fe | Φ≥1.2mm | Φ≥1.5mm | Φ≥2.0mm | Φ≥2.5mm | Φ≥3.0mm |
| Sus | Φ≥1.5mm | Φ≥2.0mm | Φ≥2.5mm | Φ≥3.0mm | Φ≥3.5mm |
| PERCEIVABLE METAL | Ferrous,Non-Ferrous,Stainless steel | ||||
| SENSITIVITY ADJUSTMENT | Auto setting | ||||
| ALARM METHOD | Buzz | ||||
| WIDTH OF CONVEYOR BELT | 330mm | ||||
| PRODUCT STORAGE | 99 kinds | ||||
| Conveying speed | Fixed speed 28m/or adjustable speed 10-30m/min[speed can be customized] | ||||
| Power supply | 220V/50-60Hz | ||||
| Motor power | 90w | ||||
| Net weight | 190Kg | ||||
| HS code | 8543709100 | ||||
