| Model | DT-560 | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Detection width (mm) | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm | ||||
| Detection height (mm) | 100mm | 120mm | 150mm | 200mm | 250mm | 300mm | ||||
| Sensitivity | Fe：≥0.8mm | Fe：≥1.0mm | Fe：≥1.2mm | Fe：≥1.5mm | Fe：≥2.0mm | Fe：≥2.5mm | ||||
| Perceivable metal | Ferrous | |||||||||
| Sensitivity modulation | Level 100 | |||||||||
| Power supply | Single-phase AC200V or 11VAC /150W | |||||||||
| Conveying speed | Fixed speed 28m/or adjustable speed 10-30m/min(speed can be customized) | |||||||||
| Housing material | PVC material | |||||||||
| Motor power | 180W | |||||||||
| Detection method | Magnet induction | |||||||||
| Detection mode | Thin material/thick material dual mode | |||||||||
🧲 Ultra-Sensitive Needle Detection
Advanced magnetic detection coils and digital signal processing locate broken needles or ferrous fragments as small as 0.8 mm, protecting garments and end users.
⚡ High-Speed Scanning
Maintains rapid conveyor throughput while delivering instant detection and rejection, keeping production lines efficient and uninterrupted.
🛡️ Safe & Reliable Design
PLC-controlled system with automatic stop and audible/visual alarms ensures operator safety and continuous, fault-free operation.
🔄 Automatic Reject Mechanism
Fast pneumatic or mechanical ejectors remove contaminated items without halting production, minimizing downtime and material loss.
⚙️ Customizable Aperture & Conveyor Options
Available in multiple tunnel sizes, belt widths, and sensitivity levels to suit various garment types and factory layouts.
🧩 Easy Integration & Maintenance
Compact, modular construction installs seamlessly on existing sewing or finishing lines. Quick-access panels simplify cleaning and service.
🌿 Energy-Efficient Operation
Optimized circuitry and intelligent standby mode reduce power consumption while ensuring stable 24/7 performance.
🌍 Global Compliance & Certification
Meets international standards, including EU CE and ISO 9001, ensuring dependable performance and smooth global distribution.
