Technical Specifications
| Dimensions | 1000mm-3500mm |
| Detection height | 80mm |
| Sensitivity | ≥0.8mm |
| Induction mode | Magnetic induction |
| Perceivable metal | Ferrous |
| Sensitivity adjustment | 0-120level |
| Alarm method | Buzz,Belt stop,Belt return |
| Count function | Passed,Failed,Total |
| Belt width | 560mmX2 |
| Motor power | 60w |
| Power Supply | 220V/50-60Hz |
| Net weight | 200Kg |
| HS code | 8543709100 |
🧲 Ultra-Sensitive Needle Detection
Advanced magnetic detection coils and digital signal processing locate broken needles or ferrous fragments as small as 0.8 mm, protecting garments and end users.
⚡ High-Speed Scanning
Keeping production lines efficient and uninterrupted.
🛡️ Safe & Reliable Design
PLC-controlled system with automatic stop and audible/visual alarms ensures operator safety and continuous, fault-free operation.
🔄 Automatic Reject Mechanism
Fast pneumatic or mechanical ejectors remove contaminated items without halting production, minimizing downtime and material loss.
⚙️ Customizable Aperture & Conveyor Options
Available in multiple tunnel sizes, belt widths, and sensitivity levels to suit various garment types and factory layouts.
🧩 Easy Integration & Maintenance
Compact, modular construction installs seamlessly on existing sewing or finishing lines. Quick-access panels simplify cleaning and service.
🌿 Energy-Efficient Operation
Optimized circuitry and intelligent standby mode reduce power consumption while ensuring stable 24/7 performance.
🌍 Global Compliance & Certification
Meets international standards, including EU CE and ISO 9001, ensuring dependable performance and smooth global distribution.
